Cathodic Protection design for ship Hull Corrosion

CATHODIC PROTECTION FOR CORROSION PROTECTION OF SHIP HULLS UNDERSTAND HOW A SHIP'S HULL IS PROTECTED AGAINST CORROSION

Corrosion is a significant concern for ships, as it can compromise the structural integrity and lifespan of the vessel. To prevent this, the shipbuilding industry employs various methods of corrosion protection to shield the hull. One of the most effective techniques is the use of anodes, which act as a sacrificial electrode in a cathodic protection system. In this text, we will explore how the hull of a ship is protected against corrosion and how the calculations of anodes are integrated into effective corrosion protection of ship hulls.

CORROSION PROTECTION OF SHIP HULLS: THE ROLE OF CATHODIC PROTECTION

Cathodic protection is a proven method to prevent corrosion on ships. It works by making the ship's hull a cathode (negative electrode) in an electrochemical cell. This process effectively stops the metal from corroding by preventing the chemical reactions that lead to rust and other forms of corrosion. Two main types of cathodic protection are used on ships: galvanic anodes and impressed current. Zinc anode, a type of galvanic anode, is especially popular in the maritime industry due to its cost-effectiveness and ease of installation.

HOW ZINC ANODES HELP PREVENT CORROSION ON SHIPS

Zinc anodes are installed on various parts of a ship's hull to provide targeted protection against corrosion. When submerged in water, the zinc anodes release a controlled amount of zinc ions, which react with the surrounding environment. This reaction creates a protective barrier around the ship's hull, preventing it from corroding. As the zinc anodes gradually corrode, they sacrifice themselves to protect the hull, hence the term "sacrificial anodes."

CALCULATION OF ANODES FOR SHIPS: ENSURING OPTIMAL CATHODIC PROTECTION

Calculating the appropriate number and size of anodes is crucial to ensure optimal corrosion protection for a ship. Factors such as the ship's size, the material of the hull, water salinity, and operational conditions all play a role in determining the required number of anodes and their placement. Calculations of anodes involve assessing the current requirements, the anode's weight, and surface area to ensure that the anodes provide adequate protection throughout their lifespan. We offer fixed design prices depending on the size of the ship, as follows. The design includes, among other things:

  • Calculation of current needs
  • System selection
  • Types of anodes
  • Size of anodes
  • Drawings
  • Material specifications

STEPS IN THE CALCULATION OF ANODES FOR CORROSION PROTECTION OF SHIP HULLS

  • Calculate the total protected surface area of the ship's hull.
  • Determine the required current density based on the type of hull material and water salinity.
  • Estimate the total current requirement by multiplying the protected surface area with the required current density.
  • Choose the appropriate type of anode considering factors such as weight and dimensions.
  • Calculate the number of anodes required to meet the total current requirement, taking into account the anode's current output and expected lifespan.
  • Determine the optimal placement of the anodes on the ship's hull to ensure even protection.

By carefully calculating and optimizing the requirements for anodes, shipbuilders and operators can effectively prevent corrosion on ships and extend the vessel's lifespan. With accurate calculation and installation of anodes, maritime professionals can ensure that their ships are protected against the harmful effects of corrosion for many years to come.

Show more
  • Original price £1,421.00 - Original price £1,421.00
    Original price
    £1,421.00
    £1,421.00 - £1,421.00
    Current price £1,421.00

    Protection Design for Ships above 51m

    In stock

    Protect your large ship from damage with our expert cathodic protection design service. Our team of experienced engineers will design a custom anod...

    View full details
    Original price £1,421.00 - Original price £1,421.00
    Original price
    £1,421.00
    £1,421.00 - £1,421.00
    Current price £1,421.00
  • Original price £948.00 - Original price £948.00
    Original price
    £948.00
    £948.00 - £948.00
    Current price £948.00

    Cathodic Protection Design for Ships between 25-50m

    In stock

     Keep your mid-sized ship in top condition with our expert cathodic protection design service. Our team of experienced engineers will design an eff...

    View full details
    Original price £948.00 - Original price £948.00
    Original price
    £948.00
    £948.00 - £948.00
    Current price £948.00
  • Original price £711.00 - Original price £711.00
    Original price
    £711.00
    £711.00 - £711.00
    Current price £711.00

    Design for Ships under 25m

    In stock

    Protect your ship's hull with our expert cathodic protection design service. Our team of experienced engineers will design an effective anode syste...

    View full details
    Original price £711.00 - Original price £711.00
    Original price
    £711.00
    £711.00 - £711.00
    Current price £711.00
